Building a Deck — Worth Every Hour
A well-built deck adds usable living space to your home and can return more than its cost in added property value. It's also one of the most achievable large DIY projects — the structural principles are simple, the timber is widely available, and the tools required are basic. Most confident DIYers can build a ground-level deck over two to three weekends.
The Most Important Decision — Timber Grade
More decks fail because of wrong timber selection than any other reason. The treatment level of your pine must match the application or the deck will rot from the inside out, often in ways you won't see until serious structural damage is done.
- Deck boards (top surface) — H3/UC3 minimum. Exposed to full weather above ground.
- Joists (frame) — H3/UC3 minimum. Even though they're partially protected by the deck boards above, they're in a humid, semi-enclosed space that promotes decay.
- Bearers — H3/UC3 if clear of the ground. H4/UC4 if close to or in contact.
- Posts in concrete or ground — H4/UC4 always. This is non-negotiable. H3 posts will fail in 3–5 years.
⚠ The most expensive deck repair call DIY Dave gets is from people who used framing pine (H2) for their posts because "it was all the hardware store had in that size." Always ask specifically for H4 treated posts. If they don't have it, go to a timber merchant.
Ready to put this into practice?
Browse 16,000 step-by-step woodworking plans — every project comes with a full cut list, materials list and diagrams. No guesswork.
Browse Project Plans → Affiliate link — small commission if you purchase, no extra cost to youTimber Species Options for Decking
Beyond treated pine, several hardwood species make excellent decking that requires less maintenance:
| Species | Durability Class | Maintenance | Cost | Notes |
|---|---|---|---|---|
| Treated Pine H3 | Good | Oil annually | Low | Most common, available everywhere |
| Western Red Cedar | Excellent | Oil or leave natural | Medium | Light, attractive, naturally rot resistant |
| Spotted Gum | Excellent | Oil annually | Med-High | Very hard, beautiful grain |
| Teak | Outstanding | Minimal | High | The benchmark for outdoor timber |
| Composite | Excellent | None | High | Not real timber but low maintenance |
The Build Sequence
- Plan and mark out
String lines to mark the deck perimeter. Check square using the 3-4-5 method. Mark post positions.
- Set posts
Dig holes minimum 450mm deep (600mm in frost-prone areas). Set H4 posts in concrete. Allow 48 hours to cure.
- Install bearers
H3/H4 bearers spanning between posts. Use post caps/stirrups for proper connection. Check level.
- Install joists
H3 joists at 450mm centres maximum. Joist hangers for a clean, strong connection to bearers.
- Lay deck boards
H3 deck boards across joists. Leave 3–5mm gaps for drainage and seasonal movement. Pre-drill all fixings.
- Trim to line and finish
Snap a chalk line and trim boards to a clean edge. Sand any rough spots. Apply decking oil.
💡 Always pre-drill hardwood deck boards before screwing — they will split without it. Use two fixings per board per joist — this prevents boards cupping. Drive fixings at a slight inward angle for better holding power.
